Substrate: PET
Thickness: 50u/0.05mm
Release force: 20-30g/in
Color: Transparent
Width: 1090mm (customizable according to customer requirements)
Length: 200m-3000m (can be cut and rewind according to customer requirements)
Purpose: Used for thermal conductive silicone calendering

Substrate: PET
Thickness: 75u/0.075mm
Release force: 350-500g/in
Color: Transparent
Width: 1010mm (customizable according to customer requirements)
Length: 200m-3000m (can be cut and rewind according to customer requirements)
Usage: Special release film for graphite rolling (re release)

Base material: PET
Thickness: 50u/0.05mm
Release force: 10~20g/in (4-D test tape MY2G)
Color: Blue
Width: 1060mm (customized according to customer requirements)
Length: 200m-3000m (can be cut and rewound according to customer requirements)
Application: Suitable for all kinds of silicone products (such as silicone protective film, silicone double-sided tape, gold finger tape, etc.)

China Factory Wholesale Blue Fluorin Release Film Pet Ultra-Light 50u 10-20g，If you have the size you need, please contact the customer to inquire about customization！

1. Superior Release Properties: Our White Fluoride Release Film is engineered with exceptional release properties, ensuring easy separation from adhesive materials. This allows for a smooth and efficient manufacturing process, saving you valuable time and resources.

2. High Temperature Resistance: Withstands Extreme Conditions: Our film is specially formulated to withstand high temperatures, making it ideal for various applications. Whether you're working with hot-melt adhesives or heat-sensitive materials, our White Fluoride Release Film will maintain its integrity, ensuring consistent performance.

3. Excellent Dimensional Stability: Precise dimensions are crucial in any manufacturing process. Our film offers excellent dimensional stability, ensuring accurate and consistent results. Say goodbye to material wastage and hello to improved efficiency.

1. Superior Release Properties: Our Blue Fluoride Release Film is engineered with exceptional release properties, allowing for easy separation from adhesive materials. This ensures a smooth and efficient production process, saving you valuable time and resources.

2. High Temperature Resistance: Withstands Extreme Conditions: Our film is specially formulated to withstand high temperatures, making it ideal for various applications. Whether you're working with hot-melt adhesives or heat-sensitive materials, our Blue Fluoride Release Film will maintain its integrity, ensuring consistent performance.

3. Excellent Dimensional Stability: Maintaining precise dimensions is crucial in any production process. Our film offers excellent dimensional stability, ensuring accurate and consistent results. Say goodbye to material wastage and hello to improved efficiency.

Product model

R903TF---- stands for "100u transparent fluorochrome release film (6-10g /in)."

● Product composition

This kind of fluorine release film is made of transparent PET(polyester film) as the substrate and coated with fluorine silicone resin on one side.
Product characteristics

1. Uniform coating, stable release force;

2. Small thickness tolerance, high transparency;

3. Low thermal shrinkage and good flatness;

4. High residual adhesion rate (≥90%), no impact on the performance of laminating materials, no pollution;

● Product Specifications

1. Width: 1060mm(can be customized according to customer requirements)

2. Length: 200m-3000m(can be cut and rewound according to customer requirements)

3. Core diameter (paper tube or plastic tube) : 3 inches (76.2mm) or 6 inches (152.4mm)

● Scope of application

Suitable for silicone products (such as three layers of hot pressing film, gold finger tape, high temperature green tape and other silicone products of the bottom film; Silicone protective film, PI tape, silicone double-sided tape and other silicone products die cutting punch).
Product packaging

1. The products are generally packaged in cartons and wooden pallet

2. Each box of products has a shipping label, and each pallet has a product list

3. Packaging can also be carried out according to customer agreement
Instructions for use

1. Static electricity may be generated during the unwinding or winding process. The static electricity layer may damage the release layer, resulting in poor stripping. If necessary, perform ESD treatment on the back or use an ESD device to eliminate static electricity.

2. In order to get the best results, it is recommended to use the product within 3 months from the date of purchase;

3. After expiration, it must be re-tested before use;

4. Recommended storage conditions: Avoid direct sunlight, and store at an ambient temperature of 25 ° C ±2 ° C and humidity of 60%±10%.

5. When using this product, please fully study whether the use (purpose, conditions) is appropriate in advance, and decide whether the product meets its standards, and the content outside the specification cannot be guaranteed.

PI tape fluorin release film,PI tape uniform coating fluorin release film,matte PI tape fluorin release film,matte fluorin release film,matte uniform coating fluorin release film

Substrate: PET
Thickness: 38um-188um
Release force: 500~900g/in (new Tesa7475 tape/20min)
Color: Transparent
Width: 1070mm (customizable according to customer requirements)
Length: 200m-4000m (can be cut and rewind according to customer requirements)
Purpose: Suitable for making the bottom film of PET hot bending film

Substrate: Optical grade PET
Thickness: 50u/0.05mm
Release force: 25-35g/in
Color: Transparent
Width: 1010mm (customizable according to customer requirements)
Length: 200m-3000m (can be cut and rewind according to customer requirements)
Usage: Special release film for OCA optical adhesive coating (re release)

Product composition
This release film is made of optical-grade PET(polyester film) as the base material, coated with silicone oil on one side for antistatic treatment.

This release film is made of optical grade PET (polyester film) as the base material, coated with single side silicone oil release agent.

Base material: PET
Thickness: 75u/0.075mm
Release force: 60-80g/in
Color: Red
Width: 1090mm (customized according to customer requirements)
Length: 200m-3000m (can be cut and rewound according to customer requirements)
Applications: Die cutting and punching fields

1. Superior Release Properties: Our Release Film is engineered with exceptional release properties, allowing for easy separation from adhesive materials. This ensures a smooth and efficient production process, saving you valuable time and resources.

2. High Temperature Resistance: Withstands Extreme Conditions: Our film is specially formulated to withstand high temperatures, making it ideal for various applications. Whether you're working with hot-melt adhesives or heat-sensitive materials, our Blue Fluoride Release Film will maintain its integrity, ensuring consistent performance.

3. Excellent Dimensional Stability: Maintaining precise dimensions is crucial in any production process. Our film offers excellent dimensional stability, ensuring accurate and consistent results. Say goodbye to material wastage and hello to improved efficiency.

Standard thickness
50μm,75μm,100μm,125μm,150μm,188μm,200μm,250μm. Other thickness can be customized according to customer's specific requirement.
Product feature and purpose
Milky white translucent polyester film, excellent electrical insulation performance, excellent processing performance, UL certified product (100-250 μm). It is mainly used for motor slot insulation, turn to turn insulation, soft composite material substrate, insulation substrate for partition between coils of dry-type transformer, and insulation gasket of electronic and electrical products.
Storage conditions
It should be stored in a clean, dry and ventilated place and should not be close to fire source, heating or direct sunlight.

Substrate: high quality PET
Thickness: 50u/0.05mm
Release force: 40-50g/in
Color: Transparent
Width: 1060mm(customized according to customer requirements)

Base material: PET
Thickness: 75u/0.075mm
Release force: 10-20g/in
Color: Transparent
Width: 1090mm (customized according to customer requirements)
Length: 200m-3000m (can be cut and rewound according to customer requirements)
Applications: Die cutting and punching fields

Base material: PET
Thickness: 38u/0.038mm
Release force: 20~30g/in
Color: Red
Width: 1090mm (customized according to customer requirements)
Length: 200m-3000m (can be cut and rewound according to customer requirements)
Applications: Die cutting and punching fields

The release film adopts green PET (polyester film) as the substrate and is coated with silicone oil release agent on the surface of the PET film.

This release film is made of Black PET (polyester film) as the base material and coated with silicone oil release agent on the surface of PET film.

Substrate: PET
Adhesive system: silicone
Substrate thickness: Contact customer service for customization
Release layer thickness: Contact customer service for customization
Adhesive force: 20-30g/in (attached to steel plate)
Color: Blue
Width: 1040mm (customizable according to customer requirements)
Length: 200m-500m (can be cut and rewind according to customer requirements)
Usage: Low viscosity silicone protective film for thermal conductive graphite sheet die-cutting

Base material: PET
Rubber system: silicone
Substrate thickness: 50u/0.05mm
Release layer thickness: 25u/0.025mm
Adhesion: 20~30g/in (stick steel plate)
Color: Blue
Width: 1040mm (customized according to customer requirements)
Length: 200m-500m (can be cut and rewound according to customer requirements)
Purpose: Thermal conductive graphite sheet die-cutting special low viscosity silicone protective film

Substrate: PET
Adhesive system: silicone
Substrate thickness: Contact customer service for customization
Release layer thickness: Contact customer service for customization
Adhesion: Contact customer service for customization (sticking steel plates)
Color: Transparent
Width: 1040mm (customizable according to customer requirements)
Length: 200m-500m (can be cut and rewind according to customer requirements)
Usage: Low viscosity silicone protective film for thermal conductive graphite sheet die-cutting

Product composition
This release film is made of transparent PET(polyester film) as the base material, coated with non-silicon release material on one side.

Substrate: PET
Adhesive system: acrylic adhesive
Usage layer thickness: 30u/0.03mm
Release layer 1:25u/0.025mm
Release layer 2:38u/0.038mm
Adhesion force: ≥ 1000g/in (with equal adhesion on both sides, tested with 25um PET original film reinforcement and steel plate)
Color: Transparent
Width: 1020mm (customizable according to customer requirements)
Length: 200m-6000m (can be cut and rewind according to customer requirements)
Usage: Bonding and fixation of materials such as display screens, touch screen frames, and graphite heat sinks
